K Swap Engine Packages

All engines are inspected and comp-tested JDM High Comp RBB K24 Engines.

ASM S2000 KSWAP packages-

Starter Pack Kit- This is the very basic kit that includes the parts necessary to install a K series engine to your S2 Trans and install it in the car.

Level1 DIY- Stage1 is a 85% ready to drop in package. Complete JDM K24, already installed Type S oil pump and 50* Cam gear, Unit2 Baffled oil pan, and all adapter parts installed. Comes with K Series Exhaust Flange and intake manifold adapter to reuse your stock F series intake which requires a little bit of cutting. Does NOT include Engine wiring or ECU.

Complete ASM-OEM-Plus- A COMPLETE K-swap package including our own engine harness and Link ECU. This engine package comes with a modified S2000 intake and exhaust [Cores required]. Simply move over your fuel rail/injectors, throttle body, and sensors. All the difficult modifying has been done. Engine harness is full plug and play, no jumpers or adapters required. Link's Plug-In ECU installs right into the OEM ECU case.

Level-2- Level2 Engine Package compes with the KPower Intake manifold, Skunk2 throttle body, and uses our Radium fuel rail/fpr Kit. We include a modified OEM S2 Exhaust header [Core Required]. Everything needed for the swap except for the ECU/Harness.

Level-3- Those wanting just a bit more power than a stock K24. We've found this package to pack the extra punch without losing any of that OEM reliability. Building off the level 2 package, but with the addition of a 4P CNC Head with some DC2.2 Cams. We typically see 240whp out of this package.

GLTC Spec- This is the package for someone wanting a simple K24 engine to put in their S2 and go track the shxt out of it. Over many seasons and literally thousands of track miles, we've figured out what works and what doesn’t. Included bigger oil pan, Fluidampr, and most importantly, engine vibration proofing to help keep sensors and throttle bodies alive.

WANT INSTALLED? An Additional $2000 and we will install and dyno tune. (This price is the ESTIMATED COST. This does not include any additional parts or services requested. This also depends heavily on the condition of the car. )

Want your engine tested/tuned? We will install your engine into our test chassis, run it to ensure everything is performing as it should, then dyno tune it. A true turn key package. This service is currently offered for $999 and only offered when you buy a complete engine package with wiring/ECU.

3 Items in Grid 4 Items in Grid List

Compare products list

COMPLETE ASM 00-05 S2000 K24 OEM-Plus Swap Package

This is it! A COMPLETE K-swap package including our own engine harness and Link ECU. Tuned base map pre-loaded on the ECU for a true turn-key solution. This engine package comes with a modified OEM S2000 intake and exhaust [Cores required]. Simply move over your fuel rail/injectors, throttle body, and sensors. All the difficult modifying has been done. Engine harness is full plug and play, no jumpers or adapters required. Link's Plug-In ECU installs right into the OEM ECU case for the OEM look. Engine harness is all pre-wired for AC as well.

$11,250.00

DIY Starter Pack S2000 K-Swap base kit.

This kit includes the basic parts you'll need to start your S2000 K20/24 swap process. Includes- Hasport K swap Engine Mounts K series engine to F series Transmission Adapter Plate ClutchMaster Steel Flywheel (We can do aluminum for cheaper but STRONGLY recommend steel) OEM Honda Flywheel Bolts (These are older B series flywheel bolts, DO NOT USE S2 Flywheel bolts with the CM flywheel)

$1,275.00

JDM K24 longblock, Prepped and ready!

Here by popular demand- Imported JDM K24 "high compression" engine prepped and ready for your K-Swap. Every engine is gone through, stripped of the useless JDM accessories, then we perform the Type S Oil Pump Conversion and install 50* VTC Cam gear. While doing this we thoroughly inspect these imported/used engines for any signs of wear/damage to ensure you are not getting a dud. We then seal it all up with a Unit2 Baffled steel oil pan, install a brand new OEM Honda USDM Water pump housing, and toss in some fresh NGK Spark Plugs.

$2,875.00

ASM S2000 K24 LEVEL-1 DIY PACKAGE

The Level-1 DIY K24 package. We start with the JDM high comp RBB K24 engine, swap in the PRB Type S Oil pump and RBC 50* VTC Gear. Beyond that, the engine is all left stock. This package comes with the engine prepped and ready for you to finish a few things. We include the intake manifold adapter to allow use of the OEM S2 intake manifold (Some modifications are required; instructions will be provided). With this you can now utilize all your OEM parts that attach to the intake manifold (Fuel rail, injectors, FPR, IAC, IAT, Throttle Body, TPS, MAP). On the exhaust side, we include a new K Series flange. This requires cutting off the F flange on your OEM header, re-clocking the two inner runners just a few degrees, and welding it all together. (or use our F2K header exchange service)

$5,850.00

ASM S2000 K24 Level-2 Swap Package

This level-2 Package includes everything you need to K24 swap your S2000 minus the wiring+ECU. We start with the JDM high comp RBB K24 engine, swap in the PRB Type S Oil pump and RBC 50* VTC Gear. Beyond that, the engine is all left stock. Typically this package makes 210-215whp on regular 91 pump fuel.

$7,699.00

F2K Swap GLTC Track-spec Engine Package

GLTC Track Spec- We start with our Level-2 K24 package and add a few additional parts and services. Over many seasons and literally thousands of track miles, we've figured out what works and what doesn’t. This is a complete drop in, ready to go track car specific solution. Included bigger oil pan, FluidDampr, and vibration proofing.

$8,699.00

ASM S2000 K24 Level-3 Swap Package

This level-3 Package includes everything you need to K24 swap your S2000 minus the wiring+ECU. We start with the JDM high comp RBB K24 engine, swap in the PRB Type S Oil pump and top it off with an RBB 4Piston CNC Cylinder head and DC2.2 camshafts. Typically this package makes 235whp on regular 91 pump fuel and 240-250 on E85.

$12,399.00

F2K Swap Level-5 Engine Package

ASM Turbo K24 Engine Package. Power output - 400-500whp Only available with in-house install. Contact us for more information.

Call for pricing

Engine Package Test & Tuning Service

Want us to fully test and tune your Kswap engine package before we ship it out? This is it. We've taken an old beat up crashed S2 and turned it into a test rig. We'll install your engine and verify its health along with tune it using your ECU. This will help save you the hassle of finding a local tuner/dyno. It'll all be ready for you to install engine and turn the key!

$999.00
